Wings hinge with bush to be welded

SKU: 876
876.16

Wings hinge with bush to be welded M16
876.18

Wings hinge with bush to be welded M18
876.20

Wings hinge with bush to be welded M20
876.22

Wings hinge with bush to be welded M22
876.24

Wings hinge with bush to be welded M24
876.27

Wings hinge with bush to be welded M27
  • adjustable
  • weld
Category:
Contact us

Technical table

cod. mm. pz/pcs A B C ØD ØE L sp M R CH.2
876.16 M16 12 27 38 21 Ø12 Ø21 84 5 M16 52-71 Es.4
876.18 M18 12 30 43 21 Ø14 Ø25 92 6 M18 57-79 Es.5
876.20 M20 10 30 43 21 Ø14 Ø25 92 6 M20 57-79 Es.5
876.22 M22 6 35 53 25 Ø17 Ø27 96 8 M22 64-80 Es.6
876.24 M24 6 35 53 25 Ø17 Ø30 106 8 M24 66-90 Es.6
876.27 M27 6 35 53 25 Ø17 Ø35 102 8 M27 67-87 Es.6
