Technical table
| Cod. | mm. | Pz/Pcs | A | C | sp | ØD | E | L | S |
|---|---|---|---|---|---|---|---|---|---|
| 110PSFL.140 | 140 | 12 | 66 | 15 | 2.7 | Ø12 | 5.8 | 150 | 2.7 |
| 110PSFL.170 | 170 | 12 | 81 | 15 | 2.7 | Ø12 | 5.8 | 180 | 2.7 |
Plug hinge to be welded with 2 wings and extractable fixed pin
| 110PSFL.140 | Plug hinge to be welded with 2 wings and extractable fixed pin mm.140 |
| 110PSFL.170 | Plug hinge to be welded with 2 wings and extractable fixed pin mm.170 |
